Alinco's latest Advanced Dual Band Mobile DMR VHF/UHF DR-MD500T Part 90 transceiver adds to its existing line-up of Digital Commercial/Business or Amateur Radio products. The DR-MD500T has features such as Color LCD Display, 55W Output Power on VHF and 40W on UHF as well as up to 4000 Memory Channels, 10,000 TalkGroup and up to 300,000 Contact lists. Capable of operating in Digital and Analog with mixed mode in VFO or Memory mode.
The DR-MD500T utilizes DVSI's AMBE+2 vocoder for Crystal clear DMR digital audio for use in noisy environments like construction sites, parks, security applications or your favorite repeaters coverage area with no noise or fading even in low lying areas. The DR-MD500T has powerful 2W audio output power to insure loud crisp receive audio.
DR-MD500T Features
- DMR Tier I and Tier II
- MAX output power 55W(VHF) / 40W(UHF)
- 4000 channels, 250 zones, 250 scan lists
- 300,000 Digital contact list
- Large 1.77 LCD Display
- Automatic Repeater Roaming
- Single or Dual Channel selectable
- Displays DMR ID, Call sign, Name.
- X-band repeat, Analog uplink/Digital downlink or vice versa
- FM Broadcasting receiver with 100 memory channels and VFO
- AES 256bit Encryption (Digital mode)
- SMS (Digital mode)
- Communication recording (Digital mode)
- Individual/Group/All call (Digital mode)
- CTCSS/DCS/DTMF/2Tone/5Tone encode and decode (Analog mode)
- Allows CSV export/import of setting parameters
- Programmable Auto Repeater Shift in VFO mode
- Kill & Stun functions
- VFO/MR Switch
- FCC Part 90 Certified
DR-MD500T Technical Specifications
Frequency Coverage | VHF 136-174MHz / UHF 400-480MHz
|
---|
Modulation | Two-Slot TDMA (Tier 1/ Tier II)
|
---|
Channel Capacity | 4000
|
---|
Zone Capacity | 250 Zones (250CH/ Zone)
|
---|
Channel Spacing | Digital 12.5KHz Analog 12.5KHz/25KHz
|
---|
Operating Voltage | 13.8V DC nominal ±15%
|
---|
Operating Temperature Range | -4°F~140°F (-20°C~ +60°C)
|
---|
Frequency Stability | +/-2.0ppm
|
---|
Antenna Impedance | 50 ohms
|
---|
Dimensions | 5.55 x 1.57 x 7.40 in. (W x H x D)
|
---|
Weight | Approx. 1.04 kg /36.68 oz
|
---|
Certifications | FCC Part 90
|
---|
Output power VHF | 55W (144-148MHz) 5W/ 25W/ 10W/ 1W
|
---|
Output power UHF | 40W/ 25W/ 10W 1W
|
---|
FM Hum and Noise (Analog) | 25KHz | 40dB / 12.5KHz | 36dB
|
---|
Spurious Emission | -36dBm@<1GHz, -30dBm@>1GHz
|
---|
Modulation (Digital) | 7K60FXD/7K60FXE
|
---|
Modulation (Analog) | 16K0F3E/11K0F3E
|
---|
Digital Vocoder | AMBE+2 (DVSI)
|
---|
RECEIVER Analog Sensitivity | 25kHz | 0.2uV 12kHz | 0.25uV
|
---|
RECEIVER Digital Sensitivity | 5% | 0.3μV 1% | 0.7μV
|
---|
RECEIVER FM Hum and Noise (Analog) | 25KHz | 45dB / 12.5KHz | 40dB
|
---|
Audio Output | 2W/ 8ohms
|
---|
Audio Distortion | Less than 5% (typical)
|
---|
|
---|
STANDARD ACCESSORIES (Included)
|
---|
Microphone | EMS-88 Microphone
|
---|
Bracket | ADFM78 (MB-130) Mobile Bracket
|
---|
Power Cable | ADUA38 DC Cable
|
---|
Mounting | Mounting Bracket w/screw kit
|
---|
Mic | Mic Hanger
|
---|
Cable | ERW-21 PC USB Data cable (MicroUSB USB cable) |
---|
Alinco DR-MD500T Reviews
Great Intro to DMR
I love it so far, but didn't know that I can't listen to commercial band. I got it for also GMRS.
